MDF X-Band

A Reliable Performer for a Variety of Uses.

Our MDF X-band combines the benefits of a veneer core on the inner plies with MDF on the

crossbands, resulting in a lighter-weight panel with exceptional fastener and screw holding

strength. This industry-leading panel delivers excellent structural strength and superior finishing

characteristics, making it ideal for laminating, custom veneer lay-up, and painted applications.

Specifications

FACE AND BACK CROSS-BAND

  • MDF

COMPLIANT

  • CARB 2/ TSCA Title Vl
  • CANFER


DIMENSIONS

*other dimensions available


  • 48.5" X 96.5"
  • 48.5" X 120.5"
  • 49" X 97"
  • 49" X 121"

THICKNESS /PLY/ WEIGHT

*weights are approximate

11.1MM 5 50 lbs
12MM 5 52 lbs
15MM 7 64 lbs
16MM 7 69 lbs
17.5MM 7 71 lbs
18MM 7 71 lbs
19MM 7 73 lbs

Features

Sourced Exclusively from Carefully Chosen Mills

  • Providing a versatile yet cost-effective solution.

High Strength & Quality

  • Excellent machinability for CNC routers.

Lightweight

  • Lighter core making it easy to handle.

High Quality Surface

  • Painting and lamination made easy.
